The Programmable Universal Timer Model:
The Programmable Universal Timer Model:
This model, as the name suggests, is an Industrial Grade Programmable Timer which can be configured in different modes, namely, as ON Timer, OFF Timer and as Cyclic Timer modes. The ON Timer mode and Cyclic Timer mode also has an added feature of level control function for source tank sensing which is best suited for Borewells with limited water source to operate periodically.
The Technical Specifications:
| Description | Single Phase | Three Phase | |
| Operating Voltage. | 230V 50 Hz AC. | 440V 50 Hz AC. | |
| System Operating Voltage. | 12V DC. | ||
| ON Duration Range. | 1 to 999 Minutes. | ||
| OFF Duration Range. | 1 to 999 Minutes. | ||
| Operating Switch Rating. | 20A. | 6A. | |
| Power Consumption | 0.05 Unit Per day. | ||
| Visual Indications. |
|
||
| Programming Method. | 3 Push Button Membrane keys. | ||
| Dimensions ( L X B X H ) | 8 inch X 9.5 inch X 4.5 inch. | GO BACK | |
