The Capacitance Based Linear Level Transmitter:

The Linear Level Transmitter consists of non-abrasive Float carrying permanent ring magnet and non-ferrous stem carrying multiple magnetic reed switches for the complete length of sensor. This Sensor comes with One Year Guarantee:

 GO BACK


The Technical Specifications:
Mechanical Specification. Description.
Sensor Stem Rigid PTFE Stem, Flexible cable with PTFE sleeve
Measuring Length
  • Up to 3Mts for Rigitd Type.
  • Up to 14Mts for Flexible Type.
Operating Temperaure -25° to 100° C.
Resolution 10mm.
Pressure Max. 5kg / cm2
Enclosure Die Cast aluminium, Weatherproof or Flameproof.
Mounting Arrangements. Threaded ½" / 1" / 2" BSPM or NPT Flange - 1" /2" ASA/ANSI/JIS/DIN
Mounting material SS 304 or SS 316.
Electrical Description Specification.
Connection Type
  • 2 Wire (Loop powered).
  • 3 wire (isolated)
  • 4 wire (Isolated)
Operating Voltage 24V DC.
Electrical Termination.
  • DIN Solenoid connector madeup of polymide
    (Suitable for Small Machine top mountings).
  • Weather proof cast aluminium enclosures.
    (Suitable for high temp., machine top or open environment).
  • Flame proof cast aluminium enclosures
    (Suitable for Group IIA and IIB zones).
Output Signal 4-20mA or 0-10V DC.  GO BACK
